Description
Factory-Direct Galvanized Steel Plates — Every DX51D to S550GD sheet rolls out of our own cold-rolling and galvanizing lines, so you skip trading margins and get mill test certificates tied to the exact heat number.
Technical Specifications
| Parameter | Value |
|---|---|
| Designation | Galvanized Steel Plate DX51D/SGCC |
| Product Type | Steel Plate |
| Steel Grade | DX51D, DX52D, DX53D, DX54D, S220GD, S250GD, S280GD, S350GD, S550GD, SGCC, SGHC, SGCH, SGH340, SGH400, SGH440, SGH490, SGH540, SGCD1, SGCD2, SGCD3, SGC340, SGC490, SGC570, G300, G550, SGCH570 |
| Standard | ASTM, JIS, ISO 9001, BIS |
| Thickness | 0.12-300mm |
| Width | 600-1500mm |
| Length | 0.6-12m (or customized) |
| Tolerance | ±1% |
| Technique | Cold Rolled Based |
| Surface Treatment | Galvanized Coated (Z30-275g/m²) |
| Spangle | Zero / Minimum / Regular / Big Spangle |
| Processing Services | Welding, Punching, Bending, Decoiling, Cutting |
| Application | Construction roofing, light industry shells, automobile parts, agriculture storage, pipe making, corrugated sheets, containers, fences |
| MOQ | 1 Ton |
| Origin | Shandong, China |
Application Suitability
| Industry | Typical Applications |
|---|---|
| Construction & Infrastructure | Anti-corrosion roof panels, roof grilles, structural cladding for industrial and civil buildings |
| Light Industry & Home Appliances | Appliance outer shells, kitchen utensil blanks, indoor decorative panels |
| Automobile Manufacturing | Corrosion-resistant body panels, underbody shields, chassis brackets |
| Agriculture & Fishery | Grain silo liners, cold-storage wall panels, frozen-food processing tables |
| Commercial & Logistics | Material storage racks, export packaging crates, container side walls |
| Pipe & Profile Fabrication | Feedstock for making welded pipes, corrugated sheets, fence posts |
Why Zinc Coating Weight Determines Whether Your Roof Panels Survive Five Years
Pick Z30 for indoor dry storage; pick Z275 for coastal construction — there is no middle ground.
I have watched project teams order Factory Direct Galvanized Steel Plate with Z30 coating for outdoor roof panels in Southeast Asia, only to see white rust bloom within two rainy seasons. The root cause is never the base steel — DX51D and SGCC perform identically under the same zinc mass — it is the mismatch between coating weight and the actual corrosion environment. Buyers who source from fragmented suppliers often receive “galvanized” plates with no coating-weight declaration on the mill test certificate, making it impossible to verify whether the material matches the project specification. [NEED_CITE: galvanized coating weight classification per ASTM A653] When certification gaps meet humid or saline atmospheres, the hidden cost is not just premature re-roofing; it is structural inspection failures and warranty disputes that dwarf the original material savings.
Matching Thickness and Spangle to Real Engineering Environments
Factory Direct Galvanized Steel Plate in the 0.12-300mm range covers everything from thin appliance wraps to heavy structural base plates. For light-gauge roofing and corrugated sheet production, regular or big spangle finishes give an aesthetic zinc pattern that contractors recognize on-site, while zero and minimum spangle surfaces provide a uniform base for subsequent powder coating or painting. Our cold-rolled base ensures ±1% thickness tolerance, which matters when press-braking DX53D or DX54D into complex profiles — inconsistent gauge causes springback variation and forces operators to re-calibrate tooling mid-batch. We run in-house physical and chemical lab tests on every heat, so the coating weight you spec is the coating weight you receive, verified before the plate leaves Jinan.
Corrosion Protection Standards and Customs Compliance
Engineering specifications for galvanized plates frequently reference ASTM A653 for the North American market or JIS G3302 for Japanese-spec projects, and customs authorities in the EU and Middle East now routinely request coating-weight declarations alongside the mill test certificate. Factory Direct Galvanized Steel Plate shipped without proper BIS, ASTM, or JIS grade marking can be held at port for re-inspection, adding demurrage costs that erase any per-ton price advantage. [NEED_CITE: galvanized steel sheet coating mass requirements in international trade] Our production holds CE, ISO 9001:2015, and third-party SGS/BV verification, meaning the documentation package — MTC, packing list, certificate of origin — is aligned with the destination country’s import requirements before the container is sealed.
Steel Grade Selection: From Commercial Quality to High-Strength Structural
The DX and SG grade families serve fundamentally different engineering functions. DX51D and SGCC are commercial-quality grades suited for light forming, roofing, and general fabrication where deep drawing is not required. Moving to DX53D, DX54D, or SGCD2 unlocks deeper draw capability for appliance shells and automotive brackets. The S-series structural grades — S220GD through S550GD — carry defined minimum yield strengths for load-bearing applications such as purlins, portal frames, and mezzanine floors. SGH340 to SGH540 target high-strength structural use in warehouses and industrial buildings, while G300 and G550 serve high-tensile applications like purlin roll-forming. Selecting the correct grade avoids both over-specification (paying for strength the design does not use) and under-specification (risking deflection or failure under load). [NEED_CITE: steel grade equivalence mapping between JIS G3302 and ASTM A653]
The Hidden Cost of Unverified Coating and Missing Mill Certificates
Ordering Factory Direct Galvanized Steel Plate based on price alone, without confirmed zinc mass and original mill test certificates, creates a cascade of downstream risks. Coating below the specified Z-value accelerates corrosion, leading to premature panel replacement. Missing or forged MTCs cause customs holds, project compliance failures, and in worst cases, demolition orders from building inspectors. Negative tolerance abuse — where actual thickness falls below the declared gauge — reduces load capacity without any visible warning, creating structural safety exposure. [NEED_CITE: consequences of non-compliant galvanized steel in construction projects] These costs never appear on the initial purchase invoice, but they routinely exceed the per-ton savings from choosing an unverified supplier.
Procurement Confidence Backed by Factory-Level Control
We manufacture Factory Direct Galvanized Steel Plate on three dedicated production lines covering over 2,800 specifications, with wall thickness capability up to 40mm and proprietary sharp-corner rectangular tube technology holding 41 invention patents. Every order passes through our in-house physical and chemical laboratory for incoming raw material inspection, in-process coating-weight measurement, and final dimensional verification — the same lab data feeds directly into your mill test certificate. As a national high-tech enterprise that participated in drafting China’s cold-formed steel industry standards, we supply state-owned enterprises, central enterprises, and listed companies across 50+ countries. You deal directly with the mill, not a trading desk, so specification changes, non-standard dimensions, and custom cutting or bending requests go straight to the production scheduler without information loss.
Documentation & Compliance
- Mill Test Certificate documenting DX51D/SGCC chemical composition and zinc coating mass (Z30-275g/m²) per heat number
- CE certificate covering EN 10210/EN 10219 compliance for European construction projects
- ISO 9001:2015 quality management certificate covering the full galvanizing and cold-rolling process
- SGS or BV third-party inspection report available for independent coating-weight and dimensional verification
- Material traceability by heat number linking each plate to its original slab, rolling schedule, and galvanizing bath record
- Customs documents including packing list, Bill of Lading, and certificate of origin formatted for EU, North American, and Middle East import requirements
Packaging, Loading & Delivery
- Cold-rolled galvanized plates bundled with steel strips and edge protectors to preserve the zinc coating and prevent corner damage during ocean transit
- Surface protection with anti-fingerprint or passivation treatment upon request, plus interleaving paper for zero-spangle and minimum-spangle finishes to avoid contact marks
- Container loading optimized for 0.6-12m plate lengths with custom cradle positioning to maximize payload per 20ft and 40ft containers
- Custom cut-to-length and bending services available before shipment, reducing on-site waste and secondary handling at the project location
- Heat number and steel grade stenciled on each bundle with weather-resistant marking for on-site identification and traceability
- FOB, CIF, and DDP logistics options with professional loading plans and real-time container tracking to 50+ countries
Start Your Procurement with Verified Specifications
Submit your required thickness, width, length, steel grade (DX51D through S550GD or SGCC through SGH540), zinc coating weight, and destination port to receive a detailed quotation including unit price, delivery schedule, and applicable certification package. Non-standard dimensions and custom processing requests — laser cutting, plate cutting, bending, punching — are quoted alongside standard catalog items within the same response.
Request Your Factory-Direct Galvanized Steel Plate Quotation
Send your specifications by email or WhatsApp to receive pricing, mill test certificate samples, and loading plans within 12 hours.
Company: Shandong Xin Jiyuan Special Steel Tube Co., Ltd
Website: www.sdxjysteel.com
Tel: +86 531 8573 6315
Mobile/WhatsApp/WeChat: +86 188 5315 7756
Email: admin@sdxjysteel.com
Address: No.11889, Jingshi West Road, Lulian Group, Jinan City, Shandong Province, China
Frequently Asked Questions
Q: How do I choose between Z30 and Z275g/m² zinc coating for my project?
A: Z30-Z90 suits indoor or dry environments such as appliance housings and interior partition panels. Z120-Z180 covers general outdoor construction roofing and fencing in moderate climates. Z200-Z275 is required for coastal construction, industrial chemical exposure, or agricultural facilities with high humidity. We can provide coating-weight test data from our in-house lab before shipment so you can verify compliance with your project specification.
Q: What tolerances can be achieved for custom cutting and bending on galvanized plates?
A: Our standard thickness tolerance is ±1% on cold-rolled galvanized plates from 0.12mm to 300mm. Laser cutting and plate cutting maintain dimensional accuracy suitable for structural fabrication, while press-brake bending is available for DX53D, DX54D, and SGCD grades with higher formability. Custom non-standard widths and lengths beyond the 600-1500mm and 0.6-12m catalog range can be produced to your drawing specifications.
Q: How do I verify steel grade compliance for EU or US customs clearance?
A: Every shipment includes an original Mill Test Certificate documenting chemical composition and coating mass per the declared standard (ASTM, JIS, or ISO). For EU projects, our CE certification under EN 10210/EN 10219 satisfies construction product regulation requirements. Third-party inspection reports from SGS or BV are available for independent verification, and all customs documents — packing list, Bill of Lading, certificate of origin — are prepared to match destination-country import formats.
Q: Can non-standard dimensions be produced with a low minimum order?
A: Yes. Our MOQ is 1 Ton, and we hold over 2,800 specifications in our production system covering thickness from 0.12mm to 300mm and width from 600mm to 1500mm. Custom non-standard sizes, cut-to-length plates, and pre-bent or punched components are available for both small trial orders and large project volumes.
Q: What is the difference between regular spangle, minimum spangle, and zero spangle finishes?
A: Regular spangle shows a visible zinc crystal pattern suitable for exposed roofing and fencing where appearance is secondary to corrosion protection. Minimum spangle reduces the pattern size for a more uniform surface, ideal for panels that will be painted or powder-coated. Zero spangle provides a completely smooth, uniform zinc surface for automotive panels, appliance shells, and deep-drawn components where surface consistency is critical.
